FTBx-88260 Report
| K-20 Layer-2 Test Results: greenriver-ctc 5G upgrade |
PASS
Report Header: K-20 Layer-2 Test Results
Report Title: K-20 Layer-2 Test Results: greenriver-ctc 5G upgrade
Report Date: 4/26/2025 12:36:13 AM
Type: EtherSAM (Y.1564)
Job Information
Job ID: RTASK4445976
Circuit ID: Lumen 04/KXGS/524350//PN
Contractor Name: K-20
Customer Name: greenriver-ctc
Operator Name: enneking
Comment: PASS
K-20 Layer-2 Test Results i
Table of contents
SUMMARY ........................................................................................................................................ 1
TEST RESULTS ................................................................................................................................. 8
TEST SETUP ................................................................................................................................... 10
FUNCTIONS .................................................................................................................................... 13
SYSTEM INFORMATION ................................................................................................................... 17
LOGGER ......................................................................................................................................... 21
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 1 of 21
SUMMARY
Results Summary
Test Status
Service Configuration Test Status Completed, Pass
Service Performance Test Status Completed, Pass
Pass/Fail Verdict PASS
Start Time 4/26/2025 12:15:44 AM
Duration 00d:00:10:51
Test Recovery 0
EtherSAM
Services Summary
Service Name Service Configuration Test Service Performance Test
1 Service 1 PASS PASS
Service Configuration Summary
Service
Name		 Directio
n		 Frame
Loss Rate		 Max Jitter
(ms)		 Max
Latency
(ms)		 Max
Throughput
(Gbit/s)		 Service
Verdict
1 Service 1 L->R 0.0E-00 0.09593 4.74997 PASS
R->L 0.0E-00 0.06769 1.12686 4.7499 PASS
Service Performance Summary
Service
Name		 Direction Frame Loss
Rate		 Max Jitter
(ms)		 Max Latency
(ms)		 Avg
Throughput
(Gbit/s)		 Service
Verdict
1 Service 1 L->R 7.5E-09 0.05167 4.75000 PASS
R->L 0.0E-00 0.04543 1.12102 4.7499 PASS
VLAN Preservation No Mismatch Detected
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 2 of 21
RX Power Level
Min Max
Power Range (dBm) -12.60 4.50
Optical Lane RX Power Level (dBm)
Min Max
0 0.87 0.94
1 0.65 0.73
2 -0.20 -0.11
3 0.00 0.07
RX Frequency
CAUI-4 Lane Frequency Offset (ppm)
Max Negative Offset Max Positive Offset
0 0.0 0.2
1 0.0 0.2
2 0.0 0.2
3 0.0 0.2
Alarms/Errors
Alarms/Errors List
Active/Historical Alarms/Errors None
Interface
Optical Lane LOS xrTableCell5 CAUI-4 Lane LOC Lane Frequency
Seconds xrTableCell6 Seconds Seconds
0 0 xrTableCell7 0 0 0
1 0 xrTableCell8 1 0 0
2 0 xrTableCell9 2 0 0
3 0 xrTableCell10 3 0 0
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 3 of 21
Ethernet
Alarms Seconds
Link Down 0
Local Fault Detected 0
Local Fault Received 0
Remote Fault 0
Hi-BER 0
Errors Seconds Count Rate
FCS 0 0 0.00E00
Jabber 0 0 0.00E00
Oversize Disabled
Runt 0 0 0.00E00
Undersize 0 0 0.00E00
Total 0
PCS Lanes
Alarms Seconds
LOA 0
Invalid Mapping 0
PCS Lanes
PCS Lane LOBL LOAML Excessive Skew
Alarms Seconds Seconds Seconds
0 0 0 0
1 0 0 0
2 0 0 0
3 0 0 0
4 0 0 0
5 0 0 0
6 0 0 0
7 0 0 0
8 0 0 0
9 0 0 0
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 4 of 21
10 0 0 0
11 0 0 0
12 0 0 0
13 0 0 0
14 0 0 0
15 0 0 0
16 0 0 0
17 0 0 0
18 0 0 0
19 0 0 0
Skew Alarm Threshold (bits) 928
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 5 of 21
PCS Lanes
PCS Lane Block Inv. Marker
Errors Seconds Count Rate Seconds Count Rate
0 0 0 0.00E00 0 0 0.00E00
1 0 0 0.00E00 0 0 0.00E00
2 0 0 0.00E00 0 0 0.00E00
3 0 0 0.00E00 0 0 0.00E00
4 0 0 0.00E00 0 0 0.00E00
5 0 0 0.00E00 0 0 0.00E00
6 0 0 0.00E00 0 0 0.00E00
7 0 0 0.00E00 0 0 0.00E00
8 0 0 0.00E00 0 0 0.00E00
9 0 0 0.00E00 0 0 0.00E00
10 0 0 0.00E00 0 0 0.00E00
11 0 0 0.00E00 0 0 0.00E00
12 0 0 0.00E00 0 0 0.00E00
13 0 0 0.00E00 0 0 0.00E00
14 0 0 0.00E00 0 0 0.00E00
15 0 0 0.00E00 0 0 0.00E00
16 0 0 0.00E00 0 0 0.00E00
17 0 0 0.00E00 0 0 0.00E00
18 0 0 0.00E00 0 0 0.00E00
19 0 0 0.00E00 0 0 0.00E00
PCS Lanes
PCS Lane BIP-8
Errors Seconds Count Rate
0 0 0 0.00E00
1 0 0 0.00E00
2 0 0 0.00E00
3 0 0 0.00E00
4 0 0 0.00E00
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 6 of 21
5 0 0 0.00E00
6 0 0 0.00E00
7 0 0 0.00E00
8 0 0 0.00E00
9 0 0 0.00E00
10 0 0 0.00E00
11 0 0 0.00E00
12 0 0 0.00E00
13 0 0 0.00E00
14 0 0 0.00E00
15 0 0 0.00E00
16 0 0 0.00E00
17 0 0 0.00E00
18 0 0 0.00E00
19 0 0 0.00E00
Clock Sync
Alarm Seconds
LOC 0
IP/UDP
Errors Seconds Count Rate
IP Checksum 0 0 0.00E00
UDP Checksum 0 0 0.00E00
Total 0
Setup Summary
Application Type EtherSAM (Y.1564)
Topology Single Port
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 7 of 21
Interface Port B1
Interface/Rate 100GE (4 Lanes) [103.125 Gbit/s]
PHY Type LR4/ER4
Connector QSFP28
Flow Control None
EtherSAM
DTS Enabled
Remote ID --
Nat Router Detection --
Local WAN IP N/A
Pass/Fail Verdict Enabled
Sub-Tests
Service Configuration Test Service Performance Test
Status Enabled
Ramp Test Enabled
Duration 00d:00:10:00
Burst selection Disabled
Duration 00:00:20
Ramp
Step Time (s) 5
Step Values
1 50 %
2 75 %
3 90 %
4 100 %
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 8 of 21
Services
Total Committed TX Rate (Gbit/s) L->R 4.7500
R->L 47.50000
Services Summary
Service
Name		 Profile Frame Size
(Bytes)		 Direction CIR
(Gbit/s)		 Max
Jitter
(ms)		 Max
Latency
(ms)		 Frame
Loss
Rate		 CBS
(Bytes)
1 Service 1 Data EMIX L->R 4.7500 2.00000 1.0E-04 --
R->L 47.50000 2.00000 15.00000 1.0E-04
TEST RESULTS
Ethernet Traffic
Frame Type TX Count RX Count
Multicast 0 24
Broadcast 2 2
Unicast 545352555 545415842
Non-Unicast 2 26
Total 545352557 545415868
Frame Size (Bytes) RX Count %
< 64 0 0.0
64 308 0.0
65 - 127 109082476 19.9
128 - 255 109082412 19.9
256 - 511 128 0.0
512 - 1023 109085810 20.0
1024 - 1518 218164734 39.9
> 1518 0 0.0
Total 545415868
Detailed EtherSAM Results
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 9 of 21
Service Configuration Test
Service 1 : Service 1
Committed Steps
Committed
Step		 Direction Frame Loss
Rate		 Max Jitter
(ms)		 Max Latency
(ms)		 Verdict Avg Throughput
(Gbit/s)
1-50%CIR L->R 0.0E-00 0.09593 PASS 2.37500
R->L 0.0E-00 0.06769 1.12686 PASS 2.3750
2-75%CIR L->R 0.0E-00 0.06508 PASS 3.56245
R->L 0.0E-00 0.04523 1.11002 PASS 3.5624
3-90%CIR L->R 0.0E-00 0.04894 PASS 4.27501
R->L 0.0E-00 0.03913 1.07678 PASS 4.2749
CIR L->R 0.0E-00 0.04172 PASS 4.74997
R->L 0.0E-00 0.03480 1.09021 PASS 4.7499
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 10 of 21
Service Performance Test
Service 1 : Service 1
Direction Average Minimum Maximum Estimate
Throughput (Gbit/s) L->R 4.7500 4.7498 4.7502 N/A
R->L 4.74999 4.74978 4.75022 N/A
Jitter (ms) L->R 0.00077 < 0.00001 0.05167 0.00079
R->L 0.00154 < 0.00001 0.04543 0.00129
Latency (ms) Round-trip 1.02162 0.92242 1.12102 N/A
Seconds Count Rate
Frame Loss L->R 1 4 7.5E-09
R->L 0 0 0.0E00
Out-of-Sequence L->R 0 0 0.0E00
R->L 0 0 0.0E00
TEST SETUP
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 11 of 21
Clock Synchronization
Clock Mode Internal
Detailed Services Configuration
IP Version IPv4
Layer Mode Mixed
Global Pass/Fail Verdict Enabled
L->R R->L
Total Committed TX Rate (Gbit/s) 4.7500 47.50000
Service 1
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 12 of 21
Service Profile
Service Name Service 1
Profile Data
Frame Size Type EMIX
Frame Size (Bytes) 70, 128, 512, 1024, 1518
SLA Parameters
L->R R->L
Information Rate
CIR (Gbit/s) 4.7500 47.5000
Performance Criteria
Max Jitter (ms) 2.00000 2.00000
Max Latency (ms) 15.00000 15.00000
Frame Loss Rate 1.0E-04 1.0E-04
Test Parameters
L->R R->L
Framing
Frame Format Ethernet II
Network Layer IPv4
Transport Layer UDP
L->R R->L
VLAN None None
Addressing
MAC IP Address UDP Port
L->R Source 00:03:01:F8:88:FC 10.112.0.1 /
255.255.255.0		 49184
Destination 00:03:01:14:55:4B 10.112.0.100 7
R->L Source 00:03:01:14:55:4B 10.112.0.100 /
255.255.255.0		 7
Destination 00:03:01:F8:88:FC 10.112.0.1 49184
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 13 of 21
L->R R->L
EtherType 0x0800 0x0800
Automatic IP (DHCP) Disabled Disabled
TTL 128 128
TOS 0x00 0x00
Default Gateway Disabled Disabled
FUNCTIONS
40/100G Advanced
Lanes Mapping & Skew
TX RX
PCS Lane Skew
(bits)		 CAUI-4 Lane Skew
(bits)		 PCS Lane
PCS Lanes
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 14 of 21
PCS Lane LOBL LOAML Excessive Skew
Alarms Seconds Seconds Seconds
0 0 0 0
1 0 0 0
2 0 0 0
3 0 0 0
4 0 0 0
5 0 0 0
6 0 0 0
7 0 0 0
8 0 0 0
9 0 0 0
10 0 0 0
11 0 0 0
12 0 0 0
13 0 0 0
14 0 0 0
15 0 0 0
16 0 0 0
17 0 0 0
18 0 0 0
19 0 0 0
Skew Alarm Threshold (bits) 928
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 15 of 21
PCS Lanes
PCS Lane Block Inv. Marker
Errors Seconds Count Rate Seconds Count Rate
0 0 0 0.00E00 0 0 0.00E00
1 0 0 0.00E00 0 0 0.00E00
2 0 0 0.00E00 0 0 0.00E00
3 0 0 0.00E00 0 0 0.00E00
4 0 0 0.00E00 0 0 0.00E00
5 0 0 0.00E00 0 0 0.00E00
6 0 0 0.00E00 0 0 0.00E00
7 0 0 0.00E00 0 0 0.00E00
8 0 0 0.00E00 0 0 0.00E00
9 0 0 0.00E00 0 0 0.00E00
10 0 0 0.00E00 0 0 0.00E00
11 0 0 0.00E00 0 0 0.00E00
12 0 0 0.00E00 0 0 0.00E00
13 0 0 0.00E00 0 0 0.00E00
14 0 0 0.00E00 0 0 0.00E00
15 0 0 0.00E00 0 0 0.00E00
16 0 0 0.00E00 0 0 0.00E00
17 0 0 0.00E00 0 0 0.00E00
18 0 0 0.00E00 0 0 0.00E00
19 0 0 0.00E00 0 0 0.00E00
PCS Lanes
PCS Lane BIP-8
Errors Seconds Count Rate
0 0 0 0.00E00
1 0 0 0.00E00
2 0 0 0.00E00
3 0 0 0.00E00
4 0 0 0.00E00
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 16 of 21
5 0 0 0.00E00
6 0 0 0.00E00
7 0 0 0.00E00
8 0 0 0.00E00
9 0 0 0.00E00
10 0 0 0.00E00
11 0 0 0.00E00
12 0 0 0.00E00
13 0 0 0.00E00
14 0 0 0.00E00
15 0 0 0.00E00
16 0 0 0.00E00
17 0 0 0.00E00
18 0 0 0.00E00
19 0 0 0.00E00
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 17 of 21
Ping & Trace Route
Network
Source MAC Address 00:03:01:F8:88:FC
Source IP Address 10.112.0.1 (Stream 1)
Destination IP Address 10.112.0.100
Ping
Timeout (ms) 4000
Delay (ms) 1000
Data Size (Bytes) 32
TTL 128
Type Of Service (TOS) 0x00
Ping Results
No. Status Reply Details
1 Successful IP=10.112.0.100, Bytes=32, Time=3 ms, TTL=127
Ping Statistics
Packets Transmitted 1
Packets Received 1
Percentage Lost (%) 0.0
Minimum Round Trip Time (ms) 3
Maximum Round Trip Time (ms) 3
Average Round Trip Time (ms) 3
Trace Route
Timeout (ms) 4000
Max Hop Count 128
SYSTEM INFORMATION
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 18 of 21
Product Name Power Blazer Series
Version Power Blazer Series 1.124
Module ID FTBx-88260
Slot ID 2
Software Product Version 1.124.0.53
Power Blazer Series 1.124
Assembly Hardware Revision D
Serial Number 1886703
Calibration Date 2/25/2025 1:12:00 PM
Transceiver System
Transceiver System Insertion Counter 1
ID TA-QSFP28
Serial Number 1890335
Revision C
Battery Good
Optical Module Insertion Counter 1
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 19 of 21
Pluggable Module
Module ID QSFP28 or later
Vendor Name ADDON
Part Number JNP-QSFP100G-LR4
Serial Number ADDEED144840
Hardware Revision J3
Revision Compliance 8
Connector Type LC
Speed 25G, 103.125 Gbit/s
Type/Compliance Code LR, 100GE-LR4-10km, 10.0 km
Mode Single-Mode Fiber, SMF
Power Class Power Class 4 (<= 3.5W)
Temperature (Max) 35.6 °C
CLEI Code
Software Options
100electrical Ethernet 100Base-TX (Electrical) Interface Enabled
100GE Ethernet 100G Enabled
100optical Ethernet 100Base-FX (Optical) Interface Enabled
10electrical Ethernet 10Base-T (Electrical) Interface Enabled
10G_LAN Ethernet 10G LAN (Optical) and 10GBASE-T (Electrical) interfaces Enabled
10G_WAN Ethernet 10G WAN optical interface Enabled
155M 155 Mbit/s Disabled
1588PTP 1588 Precision Time Protocol Disabled
1588PTPGM 1588 Precision Time Protocol Grandmaster Emulation Disabled
2.5-5GE Ethernet 2.5GBASE-T and 5GBASE-T (Electrical) interfaces Disabled
2488M 2.488 Gbit/s Disabled
25GE Ethernet 25G Disabled
40GE Ethernet 40G Disabled
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 20 of 21
50GE Ethernet 50G Disabled
52M 52 Mbit/s Enabled
622M 622 Mbit/s Disabled
9953M 9.953 Gbit/s Disabled
CPRI CPRI 2.4576 Gbit/s and 3.072 Gbit/s Disabled
CPRI-1.2G CPRI 1.2288 Gbit/s Disabled
CPRI-10.1G CPRI 10.1376 Gbit/s Disabled
CPRI-24.3G CPRI 24.33024 Gbit/s Disabled
CPRI-4.9G CPRI 4.9152 Gbit/s Disabled
CPRI-6.1G CPRI 6.144 Gbit/s Disabled
CPRI-9.8G CPRI 9.8304 Gbit/s Disabled
DCO-100ZR 100ZR Disabled
DSn Digital Signal (DS1, DS3) Disabled
eCPRI-100G eCPRI over 100G Ethernet Disabled
eCPRI-10G eCPRI over 10G Ethernet Disabled
eCPRI-25G eCPRI over 25G Ethernet Disabled
EoE Ethernet over Ethernet Encapsulation (10GE and less) Disabled
EoE_40-100GE Ethernet over Ethernet Encapsulation (40/100GE) Disabled
EoOTN Ethernet over Optical Transport Network Disabled
ETH-OAM Carrier Ethernet OAM Test Application Disabled
FC-10X Fibre Channel 10X Disabled
FC-16X Fibre Channel 16X Disabled
FC-1X Fibre Channel 1X Disabled
FC-2X Fibre Channel 2X Disabled
FC-32X Fibre Channel 32X Disabled
FC-4X Fibre Channel 4X Disabled
FC-8X Fibre Channel 8X Disabled
FlexE-100G 100G FlexE Group Disabled
FlexE-200G 200G FlexE Group Disabled
FlexE-50G 50G FlexE Group Disabled
FlexE-50G-PHY FlexE 50G Interface Type Disabled
FlexE-HiRateClient FlexE Clients at 150G and above Disabled
FlexE-LoRateClient FlexE Clients at 100G and below Disabled
FlexE-MIX FlexE Clients at mixed rates Disabled
G.mtnPathOAM G.mtn Path OAM Disabled
GCC-BERT OTN Overhead BERT and Synchronization Validation Disabled
GigE_Electrical Ethernet 1000Base-T (Electrical) Interface Enabled
GigE_Optical Ethernet 1000Base-X (Optical) Interface Enabled
iOptics Intelligent Pluggable Optic Test Application Enabled
iSAM Intelligent Service Activation Methodology Disabled
L2-Transparency L2CP Handling Test in EtherSAM Disabled
LINK-OAM Link OAM Disabled
LLDP LLDP Neighbor Discovery Disabled
MPLS MPLS Encapsulation (10GE and less) Disabled
MPLS_40-100GE MPLS Encapsualtion (40/100GE) Disabled
OBSAI OBSAI 3.072 Gbit/s Disabled
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
K-20 Layer-2 Test Results Page 21 of 21
OBSAI-1.5G OBSAI 1.536 Gbit/s Disabled
OBSAI-6.1G OBSAI 6.144 Gbit/s Disabled
ODU0 OTN ODU0 Disabled
ODUflex OTN ODUflex Disabled
ODUMUX ODU Multiplexing Payload Type 20 and 21 Disabled
OTN-INTR-THRU OTN Intrusive Through Mode Disabled
OTU1 Optical Transport Unit-1 (2.7 Gbit/s) Disabled
OTU2 Optical Transport Unit-2 (10.7 Gbit/s) Disabled
OTU2-1e-2e Optical Transport Unit-2 Overclocked (11.049/11.096 Gbit/s) Disabled
OTU2-1f-2f Optical Transport Unit-2 Overclocked (11.270/11.317 Gbit/s) Disabled
OTU3 Optical Transport Unit-3 (43.018 Gbit/s) Disabled
OTU3-e1-e2 Optical Transport Unit-3 Overclocked (44.571/44.583 Gbit/s) Disabled
OTU4 Optical Transport Unit-4 (111.81 Gbit/s) Disabled
Packet-TE Packet Time Error Disabled
PBBTE Provider Backbone Bridge Encapsulation (10GE and less) Disabled
PBBTE_40-100GE Provider Backbone Bridge Encapsulation (40/100GE) Disabled
PDH Plesiochronous Digital Hierarchy (E1, E3, E4) Disabled
RFC6349 RFC 6349 Test Application (25GE and less) Disabled
RFC6349_40-100GE RFC 6349 Test Application (40/100GE) Disabled
SDH Synchronous Digital Hierarchy Enabled
SONET Synchronous Optical Network Enabled
SyncE Synchronous Ethernet Disabled
TCM Tandem Connection Monitoring HO/LO Disabled
TST-OAM Test Over Service OAM Disabled
WANDER Time Error/Wander Test Application Disabled
LOGGER
ID Start Time Event Duration Details
1 04/26 12:15:44 AM Test Started 2025-04-26
2 04/26 12:15:48 AM Service Configuration
test started		 2025-04-26
3 04/26 12:16:23 AM Service Performance
test started		 2025-04-26
4 04/26 12:26:35 AM Test Stopped
PASS
2025-04-26_greenriver-ctc 4/26/2025 12:36:13 AM
